4CH Constant Current RF 2.4G Receiver C4-L

zoom
  • Features
  • Specifications
  • User Manual
  • Related products
Technical Parameters
● Input voltage: 12-48VDC
● Output type: PWM constant Current
● Output current: 4CH, 150-1800mA/CH(customized)
● Grey levels: 4096/CH
● Dimming range: 0-100%
● Remote distance: 30m
● Working temperature: -30℃~55℃
● Product size: L170×W50×H23mm
● Packing size: L172×W53×H27(mm)
● Net weight: 130g

Summary
● 4CH PWM constant current controller with digital numeric display and easy key operation
● Can work under Stand-alone mode or RF mode.
● Can set as 1ch dimmer, 4ch dimmer, dual color controller or RGB/RGBW controller.
● Under RF mode, full compatibility with a variety of single color dimming, dual color and RGB/RGBW remoters.
● PWM achieve 4096 levels flicker-less dimming.
● When control RGB/RGBW lamp, built in 30 change mode optional.
● Adopt 2.4GHz wireless technology, can accept up to 10 remoters control.
● Can be WiFi controlled by APP installed on IOS or Android mobile devices while working with WiFi-Relay controller.
● Work with power repeater to expand output unlimitedly.
