DMX512 to 4CH 0-10V Converter DL

zoom
  • Features
  • Specifications
  • User Manual
  • Related products
Technical parameters
● Input voltage: 5-24VDC
● Input signal: DMX512
● Output signal: 0-10V
● Dimming range: 0~100%
● Working temperature: -30℃~55℃
● Dimension: L115×W48×H67mm
● Weight: 110g

Summary
● Compatible with a variety of DMX512 masters.
● 0-10V LED driver which receives and converts DMX512 signal to 0-10V signal.
● DMX512 compliant control interface, DMX address can be set easily and shown on the digital numeric display.
● It can also work as stand-alone RGB/RGBW controller, have 30 kinds dynamic mode,adjustable speed and brightness.
● It can also work as stand-alone 4 channel dimmer, each channel adjust brightness independently, and save up to 8 groups brightness.
● Connect with 0-10V input dimming driver, such as 0-10V dimmable power supply,realize fine and smooth dimming.
