0-10V Rotary Panel Constant Voltage Dimmer KL

zoom
  • Features
  • Specifications
  • User Manual
  • Related products

Summary

● Rotary panel 0-10V dimmer, can also be used as dimming RF remote.

● Output 1 channel 0-10V signal, connect with 0/1-10V dimmable driver.

● High voltage AC input, High voltage AC relay output.

● Rotate knob to change brightness, support push and long push operation.

● Smooth dimming and switch without any flickering.

● Great compatibility with a variety of dimming RF remote.

● Adopt 2.4GHz wireless technology, remote distance up to 30m, one dimmer can accept up to 10 remote control.

● Work with WiFi-relay controller after install APP on IOS and Android system.


Technical parameter

● Input voltage: AC85-265V

● Output voltage: AC85-265V

● Output current: Max 3A

● Output signal: 0-10V(20mA)

● Static power: <1W

● Remote distance: 30m

● Work temperature: -30℃~55℃

● Product size: L86×W86×H48.5mm
